160mm Pressure Gauge with e-Gauge®-lite 4-20mA Transmitter

Stock code : EGL160

Availability : In stock

From

£237.00

 A range of high quality, industrial, all Stainless Steel pressure gauges   fitted with e-Gauge®-lite.

Need Help?

Extended Description

Specification

100mm Pressure Gauge Specification

Features

  • 160mm Dial
  • Accuracy Class 1.0 (EN837-1)
  • 1/2 inch BSP Parallel Process Thread
  • -1 bar to 700 bar Ranges
  • All Stainless Steel Construction
  • Fitted with e-Gauge-lite for 4-20mA output
  • Optional Glycerine filled (IP65)

e-Gauge®-lite Features

  • No Programming Required
  • 2-wire, 4-20mA Loop Powered Device
  • Suitable for 100mm & 160mm Gauges
  • Compatible with all types of gauge
  • Non-Contact Device, Retrofittable
  • Can also be used on Glycerine filled gauges

Application

  • Food, Beverage and Dairy
  • Chemical and Pharmaceutical Plants
  • General Industrial/Plant Construction

spec sheet
Description Part Number Stock Price Qty Basket
-30"Hg (-1 to 0) vacuum pressure range EGL160330HG 3 - 7 Days
£237.00
Add
0-15 PSI (0-1 bar) pressure range EGL16031B 3 - 7 Days
£237.00
Add
0-30 PSI (0-2 bar) pressure range EGL16032B 3 - 7 Days
£237.00
Add
0-60 PSI (0-4 bar) pressure range EGL16034B 3 - 7 Days
£237.00
Add
0-100 PSI (0-7 bar) pressure range EGL16037B 3 - 7 Days
£237.00
Add
0-160 PSI (0-11 bar) pressure range EGL160311B 3 - 7 Days
£237.00
Add
0-300 PSI (0-21 bar) pressure range EGL160321B 3 - 7 Days
£237.00
Add
0-600 PSI (0-40 bar) pressure range EGL160340B 3 - 7 Days
£237.00
Add
0-1000 PSI (0-70 bar) pressure range EGL160370B 3 - 7 Days
£247.00
Add
0-6000 PSI (0-400 bar) pressure range EGL1603400B 3 - 7 Days
£247.00
Add
0-10000 PSI (0-700 bar) pressure range EGL1603700B 3 - 7 Days
£247.00
Add
